YUCHAI YC6M290-33 M11L1-3509000-04 Pneumatic Air Compressor Assembly
PRODUCT PARAMETERS
Pneumatic Air Compressor Assembly includes :M3201-3509041 Ventilation pipe、M3201-1008103 Connecting hose、A440B-3509060 Air compressor air inlet joint part、M8801-3509340 Air compressor water inlet pipe subassembly、M36L1-3509100A Air compressor,etc.
- Adaptive Mode: YC6M290-33
- Max. power: 290 hp
- Maximum Torque：1200 Nm
If you are looking for yuchai engine parts, please feel free to contact us .
BRAND INTRODUCTION
Founded in 1992, Guangxi Yuchai Machinery Co., Ltd. (Yuchai) is a pioneering Chinese-foreign joint venture in the domestic industry to be listed abroad. Headquartered in Yulin, Guangxi Zhuang Autonomous Region, the company operates 11 subsidiaries with production bases located in Guangxi, Jiangsu, Anhui, and Shandong. As a leading internal combustion engine manufacturer in China with a comprehensive product range and diverse applications, Yuchai achieves annual sales revenue of over CNY 20 billion and produces 600,000 engines annually.
YUCHAI PARTS RECOMMENDED
YC6M290-33 Drawing Information
30. M11L1-3509000/04 Pneumatic Air Compressor Assembly | |||
| No. | Part No. | Part Name | Qty. |
| 1 | M3201-3509041 | Ventilation pipe | 1 |
| 2 | Q67638 | Loop hoop 38 | 4 |
| 3 | M3201-1008103 | Connecting hose | 2 |
| 4 | A440B-3509060 | Air compressor air inlet joint part | 1 |
| 5 | M8801-3509340 | Air compressor water inlet pipe subassembly | 1 |
| 6 | Q1201040TF2 | Stud | 1 |
| 7 | Q340B10 | Nut M10 | 1 |
| 8 | Q/YC149-10 | Compound seal washer 10 | 4 |
| 9 | M3400-3509030C | Air compressor oil inlet pipe subassembly | 1 |
| 10 | M3000-1002701A | Oil hollow bolt | 2 |
| 11 | M36L1-3509100A | Air compressor | 1 |
| 12 | YC208-C11200F | O-ring | 1 |
| 13 | Q1841065TF2 | Bolt M10×65 | 1 |
| 14 | M3400-3509001A | Air compressor gear | 1 |
| 15 | Q1841045TF2 | Bolt M10×45 | 1 |
| 16 | M3200-3509006A | Air compressor water return pipe | 1 |
| 17 | MH2L1-3509008 | Air compressor outlet connector | 1 |
| 18 | 6QA6-1307017 | Pipe connecting bolt | 4 |
| 19 | Q/YC149-14 | Seal washer 14 | 8 |
| 20 | G4606-3509014 | Seal gasket | 2 |
| 21 | M32F1-3509050 | Air pipe bracket | 1 |
Full assembly for YC6M290-33
1.MC3L2-1002000/02Cylinder Block Assembly
2.M6600-1003000/09Cylinder Head & Cylinder Head Cover Assembly
3.MC300-1004000/01Piston & Connecting Rod Assembly
4.M1100-1005000/04Crankshaft Vibration Damper Assembly
5.M3400-1006000/10Camshaft Assembly
6.M6600-1007000/07Valve Train Mechanism Assembly
7.M35L1-1008100/17& MC3L2-1008500/02 Intake Pipe Parts & Intake Connecting Pipe Parts
8.MH5Y1-1008200/04 &M13L2-1008400/02 Exhaust Pipe Parts & Exhaust Pipe Cover Parts
9.M32X2-1009000/12Oil Sump Assembly
10.M6600-1010000/03Oil Strainer Assembly
11.M6600-M66001011000/02Oil Pump Assembly
12.M32Y1-1012000/04Oil Filter Assembly
13.M16L1-1013000/05Oil Cooler Assembly
14.M6600-1014000/10Breather Assembly
15.M32X2-1015000/01Engine Start Assistant Device Assembly
16.M33L2-1028000/03Oil Dipstick Assembly
17.M11L1-1104000/14Fuel Supply Pipeline Assembly
18.M4000-1105000/02Fuel Filter Assembly
19.MC600-1111000/02Injection Pump Assembly
20.MC6L1-1130000/01Fuel Injection Pump Accessory Assembly
21.M1000-1112000/03Injector Assembly
22.M11J1-1115000/12 Fuel Cut-off System Assembly
23.MC3L2-1118000/04Turbocharger Assembly
24.M35L1-1303000/13Radiator Water Pipe & Hose Assembly
25.M11L1-1306000/04Thermostat Assembly
26.MC3L1-1307000/01Water Pump Assembly
27.MC3L1-1308000/01Fan Assembly
28.M11L1-1600000/02Power Output Assembly
29.MH4L2-3407000/07Steering Pump Assembly
30.M11L1-3509000/04Pneumatic Air Compressor Assembly
31.MH6L1-3701000/02Alternator Assembly
32.L47YA-3708000/01Starter Assembly
33.M41L3-3800000/05Instrument & Sensor Assembly
34.MH600-3904000/01Nameplate
