YUCHAI YC6M290-33 M11L1-1104000-14 Fuel Supply Pipeline Assembly
PRODUCT PARAMETERS
Fuel Supply Pipeline Assembly includes : M3500-1104050A High-pressure connecting pipe subassembly、M1200-1104240 Fuel return parts、M3500-1104060C High pressure connecting pipe joint subassembly、M3500-1104003B Fuel return pipe joint,etc.
- Adaptive Mode: YC6M290-33
- Max. power: 290 hp
- Maximum Torque：1200 Nm
If you are looking for yuchai engine parts, please feel free to contact us .
BRAND INTRODUCTION
Founded in 1992, Guangxi Yuchai Machinery Co., Ltd. (Yuchai) is a pioneering Chinese-foreign joint venture in the domestic industry to be listed abroad. Headquartered in Yulin, Guangxi Zhuang Autonomous Region, the company operates 11 subsidiaries with production bases located in Guangxi, Jiangsu, Anhui, and Shandong. As a leading internal combustion engine manufacturer in China with a comprehensive product range and diverse applications, Yuchai achieves annual sales revenue of over CNY 20 billion and produces 600,000 engines annually.
YUCHAI PARTS RECOMMENDED
YC6M290-33 Drawing Information
17、 M11L1-1104000/14 Fuel Supply Pipeline Assembly | |||
| No. | Part No. | Part Name | Qty. |
| 1 | Q/YC149-10 | Compound seal washer 10 | 6 |
| 2 | Q/YC149-8 | Compound seal washer8 | 2 |
| 3 | Q/YC901-1C0810 | Hinged bolt | 1 |
| 4 | M3500-1104050A | High-pressure connecting pipe subassembly | 6 |
| 5 | M1200-1104240 | Fuel return parts | 1 |
| 6 | M3500-1104060C | High pressure connecting pipe joint subassembly | 6 |
| 7 | M3500-1104003B | Fuel return pipe joint | 6 |
| 8 | Q/YC149-6 | Compound seal washer | 12 |
| 9 | Q/YC901-1C0610 | Hinged bolt | 6 |
| 10 | GB/T849-10 | Washer 10 | 6 |
| 11 | Q40310 | Washer 10 | 6 |
| 12 | Q150B1035TF2 | Bolt M10X35 | 6 |
| 13 | M3400-1104180 | Clamp subassembly | 1 |
| 14 | M3000-1104541 | Fuel distributor | 1 |
| 15 | Q1840835 | Bolt M8X35 | 2 |
| 16 | 630-1104305 | Fuel inlet pipe I of fuel filter | 1 |
| 17 | M1000-1104361 | Clamp bracket | 1 |
| 18 | T9000-1104090 | Clamp subassembly | 2 |
| 19 | M1000-1104400B | Fuel pipe part from fuel filter to injection pump | 1 |
| 20 | M1000-1104300B | Fuel pipe part from fuel delivery pump to fuel filter | 1 |
| 21 | Q/YC901-1C1415 | Hinge bolt | 8 |
| 22 | Q/YC149-14 | Seal washer 14 | 16 |
| 23 | M4000-1104100C | High-pressure fuel pipe part | 1 |
Full assembly for YC6M290-33
1.MC3L2-1002000/02Cylinder Block Assembly
2.M6600-1003000/09Cylinder Head & Cylinder Head Cover Assembly
3.MC300-1004000/01Piston & Connecting Rod Assembly
4.M1100-1005000/04Crankshaft Vibration Damper Assembly
5.M3400-1006000/10Camshaft Assembly
6.M6600-1007000/07Valve Train Mechanism Assembly
7.M35L1-1008100/17& MC3L2-1008500/02 Intake Pipe Parts & Intake Connecting Pipe Parts
8.MH5Y1-1008200/04 &M13L2-1008400/02 Exhaust Pipe Parts & Exhaust Pipe Cover Parts
9.M32X2-1009000/12Oil Sump Assembly
10.M6600-1010000/03Oil Strainer Assembly
11.M6600-M66001011000/02Oil Pump Assembly
12.M32Y1-1012000/04Oil Filter Assembly
13.M16L1-1013000/05Oil Cooler Assembly
14.M6600-1014000/10Breather Assembly
15.M32X2-1015000/01Engine Start Assistant Device Assembly
16.M33L2-1028000/03Oil Dipstick Assembly
17.M11L1-1104000/14Fuel Supply Pipeline Assembly
18.M4000-1105000/02Fuel Filter Assembly
19.MC600-1111000/02Injection Pump Assembly
20.MC6L1-1130000/01Fuel Injection Pump Accessory Assembly
21.M1000-1112000/03Injector Assembly
22.M11J1-1115000/12 Fuel Cut-off System Assembly
23.MC3L2-1118000/04Turbocharger Assembly
24.M35L1-1303000/13Radiator Water Pipe & Hose Assembly
25.M11L1-1306000/04Thermostat Assembly
26.MC3L1-1307000/01Water Pump Assembly
27.MC3L1-1308000/01Fan Assembly
28.M11L1-1600000/02Power Output Assembly
29.MH4L2-3407000/07Steering Pump Assembly
30.M11L1-3509000/04Pneumatic Air Compressor Assembly
31.MH6L1-3701000/02Alternator Assembly
32.L47YA-3708000/01Starter Assembly
33.M41L3-3800000/05Instrument & Sensor Assembly
34.MH600-3904000/01Nameplate
